Product Description

Product name: IP67 waterproof double seal rings solar y-connector

Rated Voltage: 1000V DC

Rated Current: 30A

Cable type: 2.5,4.6mm2

Flame retardant grade: UL94-V0

Pulse test voltage: 8000V

Material: PC/PPO

Test temperature: -40 ℃ ~ + 85 ℃

Application: Power

Pins: 3P

Supply Ability

10000 Piece/Pieces per Month

Packaging & Delivery
Packaging Details
packing by standard export carton, or according to customer's request
Lead Time:
Quantity(Pieces)    1 - 1000        >1000
Est. Time(days)       20-25        To be negotiated

Feature:

-Load high current and voltage design;

-Low contact resistance;

-Waterproof and dustproof design;

-UV-resistant design;

-Suitable for low and high temperature environments.

Introduction of photovoltaic cables

Photovoltaic cable is an electron beam cross-link cable with a rated temperature of 120 °C. It can withstand harsh weather and mechanical shock in its equipment. According to international standards, the service life of solar cables in outdoor environments is 8 times that of rubber cables and 32 times that of PVC cables. These cables and components not only have good weather resistance, UV and ozone resistance, but also can withstand a wide range of temperature changes (for example: from –40℃ to 90℃).
